Ürün Açıklaması

---

Gaz Basınç Presostadları EN1854 standardve EU 2016/426, EU 2014/35 direktiflerine uygundur.

• Ergonomik ölçülerde üretilmiştir, kullunımdaoptimum alan kaplar
• Gaz veya hava hattındaki basıncı izlemeyi sağlar.
• İstediğiniz set basıncına ayarlanabilir (skala değerinde)
• Basınç skalası geniş bir dizayna sahiptir.
• Benzer ürünlerin yerine kullanılabilinir.

Teknik Özellikler / Technical Features
Model		SP-3G	SP-10G	SP50-G	SP150-G	SP500-G
Pressure Range (mbar)		1.0 ~ 3.0	2.0 ~ 10.0	5.0 ~ 50.0	5.0 ~ 150.0	100 ~ 500
		SGPS-150V/CP can be deviate a little from setting tolerance in the range of 5.0~30mbar
Factory setting (mbar)		1.0	2.0	5.0	5.0	100
Differential pressure (△P)max		≤1.0 mbar	≤1.5 mbar	≤3.0 mbar	≤6 mbar	≤20 mbar
Permissible Pressure (mbar)		500 (50kpa)				600(60kpa)
Dielectric strength	Terminal –Terminal	:    800 VAC/1 min
	Terminal –Earth	:   1500 VAC/1 min
Insulation resistance		:   100 ㏁, Min. DC500V Megger
Setting tolerance at room temperature		±15% switch point devitationreferred to setpoint, adjusted for dropping pressure, vertical diaphragm position. ( Optional setpoint : adjusted for rising pressure)
Permissible Deviation		Permissible deviation of the set value ≤ ±15 % in the service life test according to EN 1854
Electrical connection		3-pin connector for line sockets as per DIN - EN 175 301 - 803 (without ground connection).
Measuring connection		ø 9, length 10 mm, with screw plug (Test nipple integrated in metal housing ø9)
Pressure connection		Standard : centrally on housing bottom, PF 1/4 inner thread, Optional design : additionally PF 1/4 inner thread (side under)
Degree of Protection		IP 54 as per IEC 529 (EN60529)
Leak – Tightness		PmaxX 1.5 for 1minute or Standard (EN1854 (7.2.2)
Drift		Drift of the operating pressure shall be within ±15% between before and after the endurance test.

Setting	Adjustable type
Metarials	Body, Gövde	Alminiumdiecast
	Diaphragm	NBR
	SwitchingContact	Ag-SnO2 (Optional : Au-plated)
	Switch Part	Polycarbonate
Temparature	Ambient temperature : -15 ~ 60 ℃, :  Storage temperature : - 30 ~ 80 ℃
Electrical Rating	SwitchingVoltage	AC eff. min. 24V   max. 250V DC min. 24V   max. 48V
	CarryCurrent	AC eff. max. 6A
	SwitchingCurrent	AC eff. max. 4 A at cos ϕ 1 AC eff. max. 2 A at cos ϕ 0,6 AC eff. min. 20 mA DC min. 20 mA, DC max. 1A
Control Fluid	Gas family 1, 2 and 3 according to EN 437+A1:2009; Air
